Details & Specifications
Rated Output Power
100W + 100W (8ohm)
200W + 200W (4ohm)
JEITA Power output
No
Features
Amplifier Circuit
Switching Amp
(Hypex NC500/SMPS600
by single)
Power Trans
Toroidal w/case
Volume
Electric
Wide Range
5Hz - 50kHz
Total Harmonic Distortion
0.005%
(1kHz, 8Ω)
Damping Factor
500
Input Sensitivity: Phono input
MM: 2.3 mV / 39 kohm
MC: 250
Input Sensitivity: CD/Line/Recorder
220 mV / 13 kohm
Input Sensitivity: Power Amplifier input
1.1 V / 13 kohm
SN Ratio
PHONO (MM): 88dB
PHONO (MC): 75dB
CD: 107dB
Terminal
Phono Input: yes (MM/MC)
Ext. Pre Input (Power Amp Direct): yes
Preout: yes
Audio (In/Out) Terminals *except Power Amp Direct In(or Ext-Pre) and Pre-out
6/1
(PHONO / MM&MC / CD / TUNER / LINE 1 / LINE 2 / RECORDER)
* [PHONO] and [CD] inputs = high grade terminals.
Speaker Terminal
Marantz Original
SPKT-100+
Remote Control Bus Terminal: yes (Cinch)
Display
yes (Porthole, OLED)
Control
App Control via Network Player
yes
System Remote Controller
yes
(New system remote controller to control SACD 30 and MODEL 30)
Unit (W x H x D mm)
443 x 130 x 432
Packaging Dimensions (W x H x D mm)
534 x 255 x 522
Net weight
14.8kg
Packaging gross weight
17.6kg
Power Consumption
130W
at Standby
0.2W
at Network Control On (all of Bluetooth, Ethernet, Wi-Fi, USB)
No
AC Inlet
yes
AC Outlet
No
Owner's Manual
Web Manual
Quick Start Guide
Paper
Chassis Material
SECC
Chassis Layer
Triple
Foot
New
Cosmetic
Panel Color
SG / BK
Front Center Panel
Aluminum
Back-shell
No
Side cover
Aluminum
Top Cover
Steel
Edge Lighting
yes (Dimmer)
Volume Knob
Aluminum
Input Selector
Aluminum
Bass/Treble/Balance/ REC Out Sel knobs
REC Out-->PHONO (Aluminum)
Speaker A/B button
No
Power button
Aluminum
Other knob/button (LOUDNESS, SOURCE DIRECT etc)
No
Side screw
Copper plated.
